In Stock Timing Pulleys with CMT Bushing System



Custom Machine & Tool Co., Inc. maintains inventory of parts in this catalog in order to offer same day shipping. If we don't have the quantity you're looking for we will manufacture with our standard lead time. Simply click on the Product Number within the catalog below to request your quote!




  • Product Number
  • No. of Grooves
  • Style
  • Pitch Diameter
  • Outside Diameter
  • Flange O.D.
  • Length thru Bore
  • Hub Diameter
  • Product Number
  • No. of Grooves
  • Style
  • Pitch Diameter
  • Outside Diameter
  • Flange O.D.
  • Length thru Bore
  • Hub Diameter
  • Product Number
  • No. of Grooves
  • Style
  • Pitch Diameter
  • Outside Diameter
  • Flange O.D.
  • Length thru Bore
  • Hub Diameter
  • Product Number
  • No. of Grooves
  • Style
  • Pitch Diameter
  • Outside Diameter
  • Flange O.D.
  • Length thru Bore
  • Hub Diameter
  • Product Number
  • No. of Grooves
  • Style
  • Pitch Diameter
  • Outside Diameter
  • Flange O.D.
  • Length thru Bore
  • Hub Diameter

In Stock Timing Pulleys with CMT Bushing System

2MM Gates PowerGrip® GT®2 Synchronous Pulleys

9mm (.354 in) Wide Belts (2MR09) - .530 Face Width

Product Number No. of Grooves Style Pitch Diameter Outside Diameter Flange O.D. Length thru Bore Hub Diameter
CMT26-2MR09-0606 26 3F 0.652 0.632 0.840 0.530 -
CMT28-2MR09-0609 28 3F 0.702 0.682 0.895 0.530 -
CMT30-2MR09-0609 30 3F 0.752 0.732 0.945 0.530 -
CMT32-2MR09-0609 32 3F 0.802 0.782 1.000 0.530 -
CMT36-2MR09-0909 36 3F 0.902 0.882 1.105 0.530 -
CMT40-2MR09-0912 40 3F 1.003 0.983 1.210 0.530 -
CMT45-2MR09-1212 45 3F 1.128 1.108 1.340 0.530 -
CMT50-2MR09-1212 50 3F 1.253 1.233 1.470 0.530 -
CMT56-2MR09-1616 56 6 1.404 1.384 - 0.655 1.10
CMT62-2MR09-1616 62 6 1.554 1.534 - 0.655 1.10
CMT68-2MR09-1616 68 6 1.704 1.684 - 0.655 1.10
CMT74-2MR09-1616 74 6 1.855 1.835 - 0.655 1.10
CMT80-2MR09-1616 80 6 2.005 1.985 - 0.655 1.10

3MM Gates PowerGrip® GT®2 Synchronous Pulleys

15mm (.591 in) Wide Belts (3MR15) - .780 Face Width

Product Number No. of Grooves Style Pitch Diameter Outside Diameter Flange O.D. Length thru Bore Hub Diameter
CMT19-3MR15-0606 19 3F 0.714 0.684 0.827 0.780 -
CMT20-3MR15-0609 20 3F 0.752 0.722 0.895 0.780 -
CMT21-3MR15-0609 21 3F 0.790 0.760 0.895 0.780 -
CMT22-3MR15-0609 22 3F 0.827 0.797 0.945 0.780 -
CMT24-3MR15-0909 24 3F 0.902 0.872 1.025 0.780 -
CMT26-3MR15-0912 26 3F 0.977 0.947 1.105 0.780 -
CMT28-3MR15-0912 28 3F 1.053 1.023 1.173 0.780 -
CMT30-3MR15-0912 30 3F 1.128 1.098 1.250 0.780 -
CMT32-3MR15-0912 32 3F 1.203 1.173 1.323 0.780 -
CMT34-3MR15-0912 34 3F 1.278 1.248 1.398 0.780 -
CMT36-3MR15-0912 36 3F 1.353 1.323 1.478 0.780 -
CMT38-3MR15-0912 38 3F 1.429 1.399 1.549 0.780 -
CMT40-3MR15-1616 40 3F 1.504 1.474 1.625 0.780 -
CMT45-3MR15-1616 45 3F 1.692 1.662 1.775 0.780 -
CMT50-3MR15-1616 50 3 1.880 1.850 - 0.780 -
Product Number No. of Grooves Style Pitch Diameter Outside Diameter Flange O.D. Length thru Bore Hub Diameter
CMT56-3MR15-1616 56 3 2.105 2.075 - 0.780 -
CMT62-3MR15-2020 62 6 2.331 2.301 - 0.827 1.63
CMT68-3MR15-2020 68 6 2.557 2.527 - 0.827 1.63
CMT74-3MR15-2020 74 6 2.782 2.752 - 0.827 1.75

5MM Gates PowerGrip® GT®2 Synchronous Pulleys

15mm (.591 in) Wide Belts (5MR15) - .83 Face Width

Product Number No. of Grooves Style Pitch Diameter Outside Diameter Flange O.D. Length thru Bore Hub Diameter
CMT18-5MR15-1212 18 3F 1.128 1.083 1.250 0.83 -
CMT19-5MR15-1216 19 3F 1.191 1.146 1.315 0.83 -
CMT20-5MR15-1216 20 3F 1.253 1.208 1.437 0.83 -
CMT21-5MR15-1216 21 3F 1.316 1.271 1.437 0.83 -
CMT22-5MR15-1216 22 3F 1.379 1.334 1.500 0.83 -
CMT23-5MR15-1216 23 3F 1.441 1.396 1.562 0.83 -
CMT24-5MR15-1620 24 3F 1.504 1.459 1.625 0.83 -
CMT25-5MR15-1620 25 3F 1.566 1.521 1.687 0.83 -
CMT26-5MR15-1620 26 3F 1.629 1.584 1.750 0.83 -
CMT28-5MR15-1620 28 3F 1.754 1.709 1.875 0.83 -
CMT30-5MR15-1620 30 3F 1.880 1.835 2.000 0.83 -
CMT32-5MR15-1620 32 3F 2.005 1.960 2.125 0.83 -
CMT34-5MR15-1620 34 3F 2.130 2.085 2.250 0.83 -
CMT36-5MR15-2020 36 3 2.256 2.211 - 0.83 -
CMT38-5MR15-2020 38 3 2.381 2.336 - 0.83 -
Product Number No. of Grooves Style Pitch Diameter Outside Diameter Flange O.D. Length thru Bore Hub Diameter
CMT40-5MR15-2020 40 3 2.506 2.461 - 0.83 -
CMT45-5MR15-2020 45 3 2.820 2.775 - 0.83 -
CMT50-5MR15-2020 50 3 3.133 3.088* - 0.83 -
CMT56-5MR15-2020 56 3 3.509 3.464* - 0.83 -
CMT62-5MR15-2020 62 3 3.885 3.840* - 0.83 -
CMT68-5MR15-2020 68 3 4.261 4.216* - 0.83 -
CMT74-5MR15-2530 74 6 4.637 4.592* - 1.24 3.63
CMT80-5MR15-2530 80 6 5.013 4.968* - 1.24 4.00
CMT90-5MR15-2530 90 6 5.639 5.594* - 1.24 4.50

3MM Pitch HTD® Synchronous Pulleys

9mm (.354 in) Wide Belts (3M09) - .550 Face Width

Product Number No. of Grooves Style Pitch Diameter Outside Diameter Flange O.D. Length thru Bore Hub Diameter
CMT18-3M09-0606 18 3F 0.677 0.647 0.790 0.550 -
CMT19-3M09-0609 19 3F 0.714 0.684 0.827 0.550 -
CMT20-3M09-0609 20 3F 0.752 0.722 0.895 0.550 -
CMT22-3M09-0609 22 3F 0.827 0.797 0.945 0.550 -
CMT24-3M09-0909 24 3F 0.902 0.872 1.025 0.550 -
CMT26-3M09-0909 26 3F 0.977 0.947 1.105 0.550 -
CMT28-3M09-0909 28 3F 1.053 1.023 1.173 0.550 -
CMT30-3M09-1212 30 3F 1.128 1.098 1.250 0.550 -
CMT32-3M09-1212 32 3F 1.203 1.173 1.323 0.550 -
CMT34-3M09-1212 34 3F 1.278 1.248 1.398 0.550 -
CMT36-3M09-1212 36 3F 1.353 1.324 1.470 0.550 -
CMT38-3M09-1212 38 3F 1.429 1.399 1.549 0.550 -
CMT40-3M09-1212 40 3F 1.504 1.474 1.625 0.550 -
CMT44-3M09-1212 44 3F 1.654 1.624 1.775 0.550 -
CMT50-3M09-1616 50 6 1.880 1.850 - 0.700 1.25
Product Number No. of Grooves Style Pitch Diameter Outside Diameter Flange O.D. Length thru Bore Hub Diameter
CMT56-3M09-1616 56 6 2.105 2.075 - 0.700 1.25
CMT62-3M09-1616 62 6 2.331 2.301 - 0.700 1.25

5MM HTD® Synchronous Pulleys

15mm (.591 in) Wide Belts (5M15) - .78 Face Width

Product Number No. of Grooves Style Pitch Diameter Outside Diameter Flange O.D. Length thru Bore Hub Diameter
CMT14-5M15-0909 14 3F 0.877 0.832 1.000 0.78 -
CMT15-5M15-0912 15 3F 0.940 0.895 1.063 0.78 -
CMT16-5M15-0912 16 3F 1.003 0.958 1.080 0.78 -
CMT17-5M15-0912 17 3F 1.065 1.020 1.187 0.78 -
CMT18-5M15-0912 18 3F 1.128 1.083 1.250 0.78 -
CMT19-5M15-1212 19 3F 1.191 1.146 1.312 0.78 -
CMT20-5M15-1216 20 3F 1.253 1.208 1.437 0.78 -
CMT22-5M15-1216 22 3F 1.379 1.334 1.500 0.78 -
CMT24-5M15-1216 24 3F 1.504 1.459 1.625 0.78 -
CMT26-5M15-1216 26 3F 1.629 1.584 1.750 0.78 -
CMT28-5M15-1620 28 6F 1.754 1.709 1.875 0.82 1.25
CMT30-5M15-1620 30 6F 1.880 1.835 2.000 0.82 1.25
CMT32-5M15-1620 32 6F 2.005 1.960 2.125 0.82 1.25
CMT34-5M15-2025 34 6F 2.130 2.085 2.250 1.05 1.25
CMT36-5M15-2025 36 6 2.256 2.211 - 1.05 1.25
Product Number No. of Grooves Style Pitch Diameter Outside Diameter Flange O.D. Length thru Bore Hub Diameter
CMT38-5M15-2025 38 6 2.381 2.336 - 1.05 1.25
CMT40-5M15-2025 40 6 2.506 2.461 - 1.05 1.25
CMT44-5M15-2025 44 6 2.757 2.712 - 1.05 1.25
CMT50-5M15-2025 50 6 3.133 3.088* - 1.05 1.25
CMT56-5M15-2025 56 6 3.509 3.464* - 1.05 1.25
CMT62-5M15-2025 62 6 3.885 3.840* - 1.05 1.25
